ZL | Strain relief plates
for screw assembly
The strain relief plate ZL is used for static or dynamic applications for organising and securing cables on machines, control panels or drag chains.
The design of the strain relief unit provides secure strain relief according to EN 62444. Mount of the cables or pneumatic tubing is easily done using cable ties.
By using aluminium (ZL-AB types) or brass (ZL-MS types) nuts for the screw holes, a better fit of the strain relief plate is achieved, even in high vibration environments.
Strain relief plates ZL 03 | 04 | 05 feature different comb widths. Thus providing a multi-purpose product for various cable sizes.
For multilayer installation please use DH spacers.
Part No.
32236
Specifications
Flame class
UL94-V0, self-extinguishing
Temperaturbereich Range Max
140 C°
Properties
halogen free, silicone free
Temperaturbereich Range Min
-40 C°
Advantages and benefits
Strain relief according to EN 62444
Fast and easy mounting
Cost-effective solution
High cable density
Versatile utilisation
Product variants and sizes
ZL 180
Number
32236
EAN
4251269300905
Packaging Unit
Unknown
No. of screw holes
2
ZL 60
Number
32224
EAN
4251269300844
Packaging Unit
Unknown
No. of screw holes
2
ZL 39
Number
32222
EAN
4251269300837
Packaging Unit
Unknown
No. of screw holes
2
ZL 87
Number
32228
EAN
4251269300868
Packaging Unit
Unknown
No. of screw holes
2
ZL 121
Number
32232
EAN
4251269300882
Packaging Unit
Unknown
No. of screw holes
2
ZL 140
Number
32234
EAN
4251269300899
Packaging Unit
Unknown
No. of screw holes
2
ZL 70
Number
32226
EAN
4251269300851
Packaging Unit
Unknown
No. of screw holes
2
ZL 103
Number
32230
EAN
4251269300875
Packaging Unit
Unknown
No. of screw holes
2
The strain relief plate ZL is used for static or dynamic applications for organising and securing cables on machines, control panels or drag chains.
The design of the strain relief unit provides secure strain relief according to EN 62444. Mount of the cables or pneumatic tubing is easily done using cable ties.
By using aluminium (ZL-AB types) or brass (ZL-MS types) nuts for the screw holes, a better fit of the strain relief plate is achieved, even in high vibration environments.
Strain relief plates ZL 03 | 04 | 05 feature different comb widths. Thus providing a multi-purpose product for various cable sizes.
For multilayer installation please use DH spacers.
